LWFX Decanter Centrifuge (Explosion-proof Type)

应用领域: This type of centrifuge is mainly used in the chemical, petrochemical and pharmaceutical industries involving flammable and explosive occasions. In the process of solid-liquid separation, gases are not allowed to leak into the extraneous air, or extraneous air is not allowed to enter the equipment, or it may lead to explosion. The product is configured with an airtight seal with automatic compensation function, which allows a dynamic enclosed space with micro-positive pressure to be formed inside the centrifuge during the process of operation, so as to realize good sealing and explosion-proof effect.

Introduction
Features

1 Exhaust of nitrogen with impurities 2 Feeding 3 Liquid pressure release 4 Flowmeter 5 Differential pressure gauge 6 Pressure gauge 7 Solenoid valve 8 Pressure relief valve 9 Nitrogen source 10 Explosion-proof motor 11 Hazardous gas detector 12 Ambient gas pressure 13 Solid discharge

· Unique Sealing Structure

1.Open sealing

It is applied in the occasions where no material or gas inside the equipment will be emitted to the environment and it is not necessary to separate the bowl from the ambient atmosphere.

2.Vapor-tight sealing

It is applied in the occasions where the process medium will disperse and pollute the atmosphere, or the process medium is not expected to contact the atmosphere.

3.Air-tight sealing

It is applied to ensure operation safety in the occasions where inert gases are added to the equipment from the sealing position and toxic and corrosive or flammable medium is used.
